Sunday 23 June 2019

Electro Harmonix V1 Triangle Big Muff 66#11 1971 "Green Cap"

One of the more common of all the Triangle variants, easily identified by large green film caps which usually was 120nF or 100nF.

Compact layout
And a "mojo" layout in the vein of vintage units with 0,5w carbon composition resistors. The brave one could fit it in a 1250b enclosure.
