Saturday 22 February 2020

BAJA 5E3 Deluxe Single Channel

Schematic and info HERE

Now verified. Does fendery overdrive really good. Quite bright, punchy and amp like.  It's an good idea to use log taper pots for gain and tone controls since the action is at the beginning of the rotation.





BAJA 57 Tweed Twin

Schematic and info HERE




Friday 14 February 2020

Fuzzhead Fx Pink Goat

My take on Roland AF-100 Bee Baa. Ditched the boost switch and one of the tone settings but added two new ones. "Highs" switch toggles between stock (middle position) and two settings that cut some highs:-). The other switch named "Notch" toggles between  three settings in the twin notch circuit. Middle position has 10nF to ground which gives a full sounds with lower mids. The two other settings is closer to stock Bee Baa tone with varying degree of scooped mids. Combining those switches quite ba broad variety of tones; harsh and thin to wooly and bassy.

This one is verified.
'
