Friday, 21 June 2019
God City Instruments Brutalist Jr.
Two new layouts which both is verified. One with stock circuit and one with "Response mod" which is similar to the "Reutz mod" for Proco Rat.
For more overall gain on tap you can increase 4,7k resistor to 8,2k-12k.
For more overall gain on tap you can increase 4,7k resistor to 8,2k-12k.
Stock circuit
With Response mod
With Response mod
BJF / Bearfoot Fx Model H
..and by replacing the 1,5k resistor right to the op amp witha 5k pot, you'll have a Treble control.
